Ondufil Wave Springs OUP28S
Ref: RP0283U126045I68
In stock
Or select a predefined quantity
- 1 37,13 € /unit 37,13 € 44,56 € TTC
- 5 10,22 € /unit 51,10 € 61,32 € TTC
- 10 7,63 € /unit 76,30 € 91,56 € TTC
- 20 5,39 € /unit 107,80 € 129,36 € TTC
- 50 4,35 € /unit 217,50 € 261,00 € TTC
- 100 3,66 € /unit 366,00 € 439,20 € TTC
- 250 3,04 € /unit 760,00 € 912,00 € TTC
- No minimum order
- Delivery within 1 to 3 weeks
- An advisor at your service
Technical specifications
- Outer diameter of the bearing (mm) :28
- Material :Stainless steel 17-7 Ph 1.4568
- Standard references for the bearing mounting :6001
- Diameter min (mm) :28
- Diameter max (mm) :22.4
- Section Fil ~ (mm) :2.6 x 0.45
- Number of waves :3
- Free height H0 ~ (mm) :3.4
- Working height H1 (mm) :2
- Load P1 ±15% (N) :78
Values are given as an indication and are subject to change without notice.
